SW7N65K

SW7N65K N-Channel Superjunction MOSFET

Features

  • High ruggedness

  • Low RDS(ON) (Typ 0.5Ω)@VGS=10V

  • Low Gate Charge (Typ 21nC)

  • Improved dv/dt Capability

  • 100% Avalanche Tested

  • Application: LED, Charger, PC Power


General Description

This power MOSFET is produced with super junction advanced technology of SAMWIN.

This technology enable the power MOSFET to have better characteristics, including fast switching time, low on resistance, low gate charge and especially excellent avalanche characteristics.


Samwin SW7N65K N-channel Enhanced mode TO-220F/TO-220SF/TO-251/TO-251N/TO-252/TO-220 MOSFET

Samwin SW7N65K N-channel Enhanced mode TO-220F/TO-220SF/TO-251/TO-251N/TO-252/TO-220 MOSFET

Samwin SW7N65K N-channel Enhanced mode TO-220F/TO-220SF/TO-251/TO-251N/TO-252/TO-220 MOSFET

Samwin SW7N65K N-channel Enhanced mode TO-220F/TO-220SF/TO-251/TO-251N/TO-252/TO-220 MOSFET

Samwin SW7N65K N-channel Enhanced mode TO-220F/TO-220SF/TO-251/TO-251N/TO-252/TO-220 MOSFET

Samwin SW7N65K N-channel Enhanced mode TO-220F/TO-220SF/TO-251/TO-251N/TO-252/TO-220 MOSFET
